4A0-115 Dumps Questions Increase Your Chance of Success

Passing the 4A0-115 certification exam can be challenging, which is why practicing with 4A0-115 questions can greatly increase your chances of success. Nokia 4A0-115 dumps questions help you become familiar with the exam format. The 4A0-115 questions are designed to mimic the actual exam, which means that you'll get a feel for the types of questions you'll encounter, the difficulty level, and the time limit. All the 4A0-115 exam dumps questions are the latest version for you to study. Test free 4A0-115 exam questions below.

Page 1 of 2

1. A Layer-3 EVPN service is configured to use the interface-ful unnumbered forwarding model.

Which of the following statements is FALSE?

Each participating PE advertises a MAC/IP route that carries the MAC address of SBD IRB interface.

IP-Prefix routes exchanged between PES include a non-zero MAC address as an overlay index.

The VPRN service is configured to allow the advertisement of IP prefixes.

The SBD IRB interface configured in the VPRN service has no IP address assigned to it.

 Loading...

2. Which of the following statements about the EVPN route types used to support multi-homing is TRUE?

Ethernet segment (ES) routes indicate the redundancy mode of the Ethernet segment.

ES routes provide the ESI label required to support the split-horizon mechanism.

Auto-discovery (A-D) routes are imported by all PES participating in the EVPN service.

A-D per Ethernet segment routes indicate the desired designated forwarder election algorithm.

 Loading...

3. Based upon the exhibit, which of the following statements is FALSE?

VPLS 10 must be configured with two BGP instances on PE3 and PE4.

On PE3 and PE4, VPLS 10 must be configured with two different route-distinguisher values: one for VXLAN and another for MPL

On PE3 and PE4, VPLS 10 must be configured with two different route-target values: one for VXLAN and another for MPL

A BGP export policy is required on PE3 and PE4 to ensure that IMET routes originated with VXLAN encapsulation are not advertised to the peer across the core network.

 Loading...

4. In the exhibit, the interface-ful numbered model is used for the Layer-3 EVPN service.

Which of the following is used as the source MAC address in the packets sent from PEI when forwarding customer traffic to Host 2?

MAC-OI

MAC-03

MAC-04

MAC-11

 Loading...

5. Based on the exhibit below, which of the following statements is FALSE?





When forwarding BUM traffic, the local PE must replicate the traffic and send it as unicast to the advertising neighbor.

The MPLS label 524284 presented indicates the service label value that the neighbor 10.10.10.2 uses to forward BUM traffic to PE

When forwarding BUM traffic, the local PE uses an MPLS transport tunnel towards the advertising neighbor.

The IMET route is imported by a local VPLS configured with a route-target value of 65100:10.

 Loading...

6. Which of the following EVPN routes are exchanged to support the operation of a multi-homed EVPN VPWS?

Auto-discovery per EVPN instance (A-D per EVI) routes and Auto-discovery per Ethernet segment (A-D per ES) routes only

MAC/IP routes, A-D per EVI routes, and A-D per ES routes

A-D per EVI routes, A-D per ES routes, and Ethernet segment (ES) routes

A-D per EVI routes and ES routes only

 Loading...

7. Examine the exhibit.





Which of the following statements about the EVPN routes exchanged for EVPN VPWS 2 is TRUE?

PEI advertises an A-D per EVI route that includes a tag ID set to 40.

PEI advertises an A-D per EVI route that includes a non-zero Layer-2 MTL

PE2 advertises an A-D per EVI route that includes a P flag set to

All PES advertise a MAC route that includes a non-zero MPLS label.

 Loading...

8. The interface-ful numbered model is used for a Layer-3 EVPN service.

Which of the following statements is FALSE?

EVPN routes are advertised with a service label associated with the SBD VPL

IP-Prefix routes exchanged between PES include a non-zero gateway IP address as an overlay index.

EVPN MAC/IP routes are used to advertise the MAC and IP addresses of local hosts.

EVPN MAC/IP routes are used to advertise the MAC and IP addresses of SBD IRB interfaces.

 Loading...

9. Which of the following statements about EVPN auto-discovery per Ethernet segment (A-D per ES) routes is TRUE?

The updates include an Ethernet segment identifier label that is used in loop prevention.

The updates advertise the Ethernet segment availability in a given EVPN service.

The updates include an MPLS label that is set to a non-zero value.

The updates include an Ethernet tag ID that is set to zero.

 Loading...

10. In the exhibit, the default algorithm is used to elect the designated forwarder (DF) on ESI 1.

Which PE is elected as DF for VPLS 10?

PEI

PE2

PE3

PE4

 Loading...

Page 2 of 2

11. Based upon the exhibit,





Which of the following statements about the forwarding of BUM traffic is FALSE?

PE3 replicates the traffic and sends it to all PES in its VPLS I flooding list.

PE3 adds an ESI label to packets forwarded to PEI because PEI is connected to the same Ethernet segment.

PEI forwards the traffic received from PE3 to CEI, and CEI discards it based upon the ESI label.

PE2 decapsulates the packets received from PE3 and forwards the frames to CE2.

 Loading...

12. Which of the following statements about PE-to-PE MAC address advertisement is FALSE?

The service distinguisher (label or VNI) is advertised with the MAC/IP EVPN update.

Route targets are used to uniquely identify routes between EVIS in the case of MAC address overlaps.

A PE uses a single MP-BGP session with a remote peer to exchange the routes for all EVIs.

A PE advertises locally-learned MAC addresses to remote PES using EVPN type-2 routes.

 Loading...
